U8A-15 UTILITY AIR WINCH

Description:

The Model U8A-15 is a rugged, economical tugger for

use in the plant maintenance, construction, mining,

oilfield, and marine industries. Engineered using heat

treated high strength aluminum alloy the U8A-15 is a

very lightweight and portable unit that can be handled by

one man. An oil bath precision machined worm drive

gearbox ensures positive load holding for excellent

position control

Standard Features:

Lightweight aluminum alloy frame and drum construction

Fully enclosed worm gearbox provides positive load

holding and positioning characteristics

Direct mounted reversing drum switch on electric models

Self locking worm drive provides accurate load positioning

and load holding when control handle is released

Permanent bolt down and temporary lashing hooks for

mounting versatility

Cast aluminum carrying handles for easy portability

Dual mufflers are standard for quieter operation

Line Pull - 1,500 lbs at full drum**

Speed - 40 fpm**

** Performance is based on air supply of 125 CFM @90 PSI

Optional Features:

Hand held remote pendant with push button controls

In-line filter/lubricator/regulator assembly

Winch cables

Extended drum lengths
